SINOTRUK HOWO 4x2 8000 Liters Capacity 3.856L Engine Capacity Fuel
Tank Truck
Description:
The oil tank truck is mostly used for the transportation and
storage of oil derivatives, such as diesel, gasoline, coal tar,
lubricating oil, etc. According to different application and
service environment, this vehicle has multiple oil feeding or
delivering functions, like oil suction, oil pumping, separate
loading of multiple oils, and so on.
1. The dedicated part of the oil tank truck is composed of the tank
body, power takeoff, transmission shaft, gear oil pump, pipe
network system, and other components. The pipe network system
consists of pipes, oil pump, filter screen, two-way ball valve, and
three-way ball valve.
2. The tank can be made of aluminum, carbon steel, stainless steel,
or plastic, so as to transport industrial oil, edible oil, crude
oil, and other kinds of oil.
3. The tank can be divided into separate parts to hold different
oils, foods, and chemicals. It can be added with refueling gun,
flow meter, tax fuel dispenser, 15m automatic back-to-position
refueling reel, and other devices.
4. The pipe network system adopts full aluminum alloy. The upper
and lower dual network can realize self-priming and gravity
discharge.
Specification:
| Truck Brand | SINOTRUK-HOWO |
| Dimension(Lx W xH)(unloaded)(mm) | 6500*2400*2480 |
| Approaching angle/Departure angle(°) | 20/19 |
| Overhang(front/rear) (mm) | 1160/1475 |
| Wheel base (mm) | 3800 |
| Max speed(km/h) | 79 |
| Curb weight(kg) | 4030 |
| Gross Vehicle Weight(kg) | 7995 |
| Oil Tank | Tank volume:5000L gear oil pump,unresettable flowmeter,measuring pressure unloading
port,non-measuring pressure unloading port,self-unloading |
| Engine | Model | YN4102 |
| Fuel type | Diesel |
| Horse Power, max(kw/rpm) | 116HP |
| Emission | EURO III |
| Fuel tanker capacity(L) | 120L |
| Transmission | Model | WLY6T46,6 froward & 1 reverse |
Brake system
| Service brake | Dual circuit compressed air brake |
| Parking brake | Spring energy,compressed air operating on rear wheels |
| Auxiliary brake | Engine exhaust brake |
| Front axle | 2.7 |
| Rear axle | 5.5 |
| Color | As per customer’s requests |
| Tyre | 8.25R16, (one spare tyre).7 units |
| Electrical system | Battery | 24V |
| Cab | 2080 single cab,3 seats.with A/C. Radio,sun shield,clutch booster,adjustable steering
wheel,heater,air drier,etc |
Detailed photo:
