Description:
A bulldozer is an engineering vehicle.
The front is equipped with a large metal bulldozer. When in use,
put down the bulldozer, shovel forward and push mud, sand and
stones, etc.
The position and angle of the bulldozer can be adjusted, and it can
independently complete excavation, earth moving and unloading. soil
work.
It is mainly suitable for shallow excavation and short-term
transportation of the first to third types of soil, such as site
cleaning or leveling, excavation of foundation pits with small
depth and backfilling, and construction of subgrades with small
heights.
Specification:
| Engine | Brand | Cummins |
| Model | NT855-C280 |
| Rated speed rpm | 1800 |
| Rated power kw | 162 |
| Fuel consumption g/kw.h | 212 |
| Transmission | Number of gears | 3F/3R |
| Work equipment | Blade height mm | 1315 |
| Blade width mm | 3725 |
| Max.depth mm | 540 |
| Max. tilt adjustment mm | ≧735 |
| Pitch adjustment mm | 55 |
| Rated power/roation : kW/rpm | 115/2200 |
| Overall dimensions | Basic mm | 6510*3725*3325 |
| With ripper and ROPS mm | 6793*3725*3400 |
Photos:
Engine:
* Equipped with electronically controlled static pressure drive
system to automatically adapt to load changes,
* Intelligent matching technology reduces comprehensive fuel
consumption by 10~15%.
* Hydrostatic drive with electrical control system ensures that the
pump absorbs all engine torque.
* When the engine is working at high altitudes or has wear, the
control system can detect performance degradation and cause the
reducer to absorb torque.
Cab
* Ergonomic hexahedron cab, large space and good vision.
* Suspended single accelerator pedal, small size, large foot space
and high operating comfort.
* Widely adjustable seat and armrests provide the driver with the
most comfortable operating posture.
* The whole cab is sealed with shock absorption system, which
reduces the noise inside the car by 3~4dB.
* The whole machine safety channel system ensures the safety of the
driver.
* Adopt electric control traveling system and hydraulic pilot
control working device, the traveling system and working device can
be controlled by a single handle.
* Small operating force, precise control, flexible and light
operation, high operating comfort and high work efficiency.
* The hydrostatic drive system can realize stepless speed change,
on-load steering, pivot steering, strong flexibility, and is
suitable for various working conditions.
